SCT PolyLiner
Cost-Effective Solution for Permanent or Temporary Site Protection
SCT PolyLiner is a high performance, prefabricated polyurea liner with a geotextile backing. This high performance composite liner is an environmental containment solution offering superior protection for markets not limited to: Oil/ Gas, Mining, Industrial, & Agricultural. PolyLiner provides protection against spills and leaks from tanks, flow lines, pipes, equipment, vehicles, or vessels reducing or eliminating the need for remediation.
Manufacturing
PolyLiner showcases our cutting-edge, proprietary polyurea coating which is applied by an automated, state-of-the-art manufacturing process which ensures industry leading consistency and coverage. Its design maintains extreme abrasion resistance, flexibility, and puncture resistance in the most extreme climates leading to minimal maintenance and long lifespan.
Functional, Reusable, & Recyclable
SCT PolyLiner is extremely durable, featuring extreme abrasion resistance and puncture resistance. Designed to have superior flexibility and durability, it can be cleaned, transported, and reused multiple times for a variety of applications. In conjunction with the SCT 8045 polyurea, the PolyLiner can be attached to our SCT FlexBerm, steel walls, concrete, wood, foam and other substrates to create a containment system. The liner can be cut and trimmed to size which allow for custom sizes for equipment, trucks, tanks and individual smaller portable containments.
Features & Benefits
- -40°F (-40°C) Flexibility
- Extreme Abrasion Resistance
- Lays Flat for Quick & Easy Installation
- Very Good Chemical Resistance
- Non-Woven and Woven Geotextile Options
- Excellent Thermal Stability
- Maintenance-free and easily cleaned
- Reusable on multiple sites
- Custom Sizes, Colors, and Thickness
- Manufactured with Automated Equipment to ensure a consistent, impermeable layer of SCT 8045 polyurea
- Engineered and tested to resist puncturing, tearing, & most chemicals
- Longer lifespan and more durable than HDPE to provide industry leading environmental protection from vehicles and spills
Performance Data
| Elastomer Physical Properties | Value | Test Method |
|---|---|---|
| Hardness (Shore A) | 80 | ATSM D2240 |
| Tensile Strength (psi) | 2,200 | ASTM D412 |
| Elongation (%) | 510 | ASTM D412 |
| Tear Strength (pli) | 355 | ASTM D624 |
| Abrasion Resistance CS-17, 1000 cycles * | .0000g (0mg) .0000% loss | ASTM D4060 |
| Abrasion Resistance H18,1000 cycles | .08g (80mg) .003% loss |
ASTM D4060 |
*CS-17 test resulted in a net mass gain over 2,000 cycles due to the CS-17 wheel abrading away
Standard Sizes
| SCT PolyLiner | Mils | ft² / Roll |
|---|---|---|
| 50′ x 5′ | 60 | 250 |
| 50′ x 10′ | 60 | 500 |
| 50’ x 15’ | 60 | 750 |
| 100’ x 15’ | 60 | 1,500 |
Colors Available: :
Standard Colors:
- Tan
- Black
- Covert Green
- Shale Green
Any color available upon request
Textile Options:
- 12 oz. non-woven geotextile
- 16 oz. non-woven geotextile
- 2x2 woven geotextile
